Product Details:
Payment & Shipping Terms:
|
| Product Name: | Chain Block | Capacity: | 0.5-20ton |
|---|---|---|---|
| Control Method: | Manual Control | Chain Material: | G80 Chain |
| Limit Switch: | Including | Lifting Height: | 3-18m |
| Keywords: | Hand Chain Hoist, Manual Block | OEM: | Accept |
| Capacity ton | Lifting height m | Running test load KN |
Effort required to lift rated load N |
Strands of load chain |
Diameter of load chain mm |
Net weight kg/3M |
| 0.5t | 3-18 | 7.5 | 221 | 1 | 6 | 9 |
| 1t | 3-18 | 15 | 304 | 1 | 6 | 12 |
| 1.5t | 3-18 | 22.5 | 343 | 1 | 8 | 19 |
| 2t | 3-18 | 30 | 410 | 2 | 6 | 19 |
| 3t | 3-18 | 45 | 343 | 2 | 8 | 27 |
| 5t | 3-18 | 75 | 414 | 2 | 10 | 42 |
| 10t | 3-18 | 150 | 414 | 4 | 10 | 83 |
| 20t | 3-18 | 300 | 414×2 | 8 | 10 | 193 |
